BALL VALVE

Ball Valves are designed and manufactured in accordance with latest international standards like API 6D, API 608 and BS 5351 to provide highest safety, efficiency and accuracy.

Ball Valves regulate and control the flow of various fluids by the process of opening and closing of Valve. The valves provided by us are highly demanded due to its unique features like dimensional accurateness, brilliant performance and low maintenance.

The “INVENT” Ball Valves are economically priced and designed to last. These Valves provide exceptional performance in even the most stringent applications found in the Oil & Gas industry and other industries. We offer a wide range of elective seat and seal materials.

We are Manufacturing Ball Valves in Single Piece; Two-Piece & Three-Piece cast steel constructions. These Valves are manufactured to the highest possible quality standard. Many of our threaded and socket weld Ball Valves are manufactured according to the ASME B16.34 design standard. These valves provide the exceptional performance in even the most stringent applications found in the Oil & Gas industry and other industries. We manufacture high quality Trunnion mounted Ball Valve which are manufactured under, for more information contact us right now.

Material
Cast Carbon Steel – WCB, WCC, etc.
Low Carbon Steel – LCB, LCC, etc.
Martensitic Steel – WC1, WC6, WC9, C5, C12, CA15, etc.
Austenitic Stainless Steel – CF8, CF8M, CF3, CF3M, CN7M, CG3M, etc.
Duplex Stainless Steel – CD4MCuN, CD3Mn, etc.
Design Standard
API 6D | BS 5351 | BSEN ISO 17292
Construction
1 Piece | 2 Piece | 3 Piece (Floating ball & trunnion mounted, soft seated | metal seated | Fire Safe | blow out proof stem | anti static)
Testing Standard
API 598 | API 6D
Pressure Rating
150# | 300# | 600# | 900# |2500#
Size Range
(Cast valve)2" to 12"
(Forged valve)1/2" to 2"
End Connection
screwed | Socket weld | Flanged | flanged RTJ | Butt weld (cast valve)
Flanged | socket weld screwed | Butt weld
Operation
Lever | Gear | Pneumatic Actuator | Electric Actuator
Option
Full port | Reduce port

Three way Ball Valve

Sizes DN6 to DN600 ( NPS ¼ to NPS 24)
Pressure Rating Class 150 & PN10 / PN 16 & Table D / Table E
Material Construction Cast Carbon Steel – WCB, WCC, etc.
Low Carbon Steel – LCB, LCC, etc.
Martensitic Steel – WC1, WC6, WC9, C5, C12, CA15, etc.
Austenitic Stainless Steel – CF8, CF8M, CF3, CF3M, CN7M, CG3M, etc.
Duplex Stainless Steel – CD4MCuN, CD3Mn, etc.
Ductile Iron – Grey Cast Iron, S.G. Iron, etc.
Design & Manufacturing Standard BS EN ISO 17292 / API 6D / API 608
Face to Face Std. ASME B16.10
End Connection Std. ASME B16.5 & ASME B16.10
Testing Standard API 598 / BS 6755 Part-I
Type of Bore Regular (Reduced) & Standard (Full Bore)
End Connection Type Flanged Ends, Screwed Ends, Socket Weld Ends, Butt Weld Ends, Victaulic Ends, Tri-Clover Ends, etc.
Seat Design Soft Seat – PTFE, RPTFE, PEEK, etc.
Fire Safe Design,
Spring Loaded Type, etc.
Operated Type Hand Lever, Gear, Pneumatic Actuator, Bare Shaft, etc.
